SHEEP MOUNTAIN SET UP INSTRUCTIONS
1. Remove contents from stuff sack. Spread out the tent body.
2. Stake out the four corners.
3. Assemble the poles. Ensure each pole section is fully seated into the next byhand instead of allowing the shock cord to snap them together.
4. Insert one pole into each pole sleeve on the top of the tent body.
5. Insert each pole tip into the corresponding webbing grommet. Poles will inter-sect over both the head and foot ends of the tent creating an eye shape overthe tent body.
6. Attach all plastic clips on tent body to the poles.
7. Drape the rainfly over the tent body, orienting so the colors of the webbing onthe rainfly match the webbing on the tent body.
8. Attach the hook and loop tabs on the underside of the fly to the correspondingpoles for best stability.
9. Make sure the webbing located at the corners of the fly is completely slack-ened. Attach the buckles on the fly to those on the tent body.
10. Tighten the webbing on each buckle as needed to keep the fly taut.
11. Stake out the vestibules, then stake out and tension all remaining guylines.
12. Low Vent Set Up: For increased ventilation, hook the cord located at the bot-tom of the vestibule door to the toggle at the top of the zipper located on theunderside of the fly.Separate 6” length pole segment included for emergencyfield repair. Slide repair pole over the break to act as a splint.Secure splint in place with tape.Sheep Mountain 1 Tent Body and Fly
Please do not edit the
Cut here to remove. Do Not Tear!Thanks for choosing a Big Agnes tent!Please feel free to contact us if you have any questions or comments.www.support.bigagnes.com
HELPFUL HINTS FOR TENT SET UP
Our tents are easy to set up but we suggest you practice once at home before using them for the first time to avoid late night bickering with tent mates while fumbling around in the dark.
Before pitching tent, clear campsite of debris that may pierce tent floor.
We recommend staking out all corners, vestibules and guylines to increase space and venti-lation. Securely staking out your tent and all guyline is crucial to maintaining the structural integrity of your tent.
Hang onto your stuff sacks or they’ll blow away and create backcountry litter.
Pull on the pole sleeve fabric when inserting poles to avoid any bunching in the material.
Push rather than pull poles through pole sleeves.
Thanks for choosing a Big Agnes tent!
Please feel free to contact us if you have any questions or comments.
support.bigagnes.com | 877.554.8975
